A solid or concentric stranded central steel core is surrounded by one or more layers of concentric stranded aluminum alloy 1350. The wire is protected from corrosion with a zinc coating….Product Details.
| Wire Size | 477 MCM |
|---|---|
| O.D. (Inches) | 0.814 |
| Ampacity | 646 |
How many amps is #4 ACSR good for?
A solid or concentric stranded central steel core is surrounded by one or more layers of concentric stranded aluminum alloy 1350….Product Details.
| Wire Size | 4/0 AWG |
|---|---|
| # of Conductors | 1 Conductor |
| O.D. (Inches) | 0.563 |
| Ampacity | 357 |
What does 477 ACSR weigh?
Weight lb/1000FT: Aluminum: 449.6. Weight lb/1000FT: Steel: 205.4.
What is AAAC cable?
AAAC – All Aluminum Alloy Conductor is used for primary and secondary overhead transmission and distribution services. This has been designed utilizing a high-strength aluminum alloy to achieve a high strength-to-weight ratio and better sag characteristic. The conductor has a higher resistance to corrosion than ACSR.
How many types of ACSR are there?
Types of ACSR Conductors:
| Sr. No. | Types of ACSR Conductors |
|---|---|
| #1. | All Aluminum Conductor – AAC |
| #2. | Aluminum Conductor Aluminum Reinforce – ACAR |
| #3. | All Aluminum Alloy Conductors – AAAC |
| #4. | Aluminum Conductor Steel Reinforced – ACSR |
What does KCMil stand for?
thousand circular mils
KCMil – A method of measuring conductor size that stands for thousand circular mils. K represents kilo for 1,000. C represents circular, and mil, M, is 1/1000 of an inch. A wire that is one mil in diameter has an area of one circular mil or 1 KCMil.
What is ACSR wire used for?
ACSR wire, or Aluminum Conductor Steel Reinforced cable, is an electrical cable mainly used for distribution services as well as bare overhead transmission, both primary and secondary, in various industrial settings, including construction.
How many amps can a 477 Hawk ACSR run?
Allowable Ampacity for 477 HAWK ACSR: 659 Amps
What are the 477 Hawk cables made of?
477 hawk steel reinforced cable, 477 hawk acsr wire, 477 hawk acsr cable, 477 hawk aluminum conductor steel reinforced, 477 hawk acsr aluminum conductor steel reinforced, 477 hawk all aluminum conductor, 477 hawk aluminum alloy cable, 477 hawk abrasive resistant cable, 477 hawk transmission overhead, 477 hawk overhead power line components.
