If the coil span is equal to the pole pitch(ie, when we connect one coil side in the first slot of north pole and the other side in the first slot of the adjacent south pole) the winding is called full pitched coil . If coil span is less than pole pitch the winding is known as short pitched winding.
What is meant by short pitched coil?
The coil span of a full pitch coil is always 180° electrical. Similarly, if the distance between two coils sides of a coil placed in the slot is less than the pole pitch ( i.e., less than 180° electrical ), it is known as ‘Short Pitch Coil or Chorded Coil’ as shown in the below figure.
What is short chording?
This can be seen in the figure below. Short Pitch / Chorded Coil: Thus we can define a Short Pitch Coil as the coil having the coil span (Coil Span is defined as the space angle between the two coil sides of a coil) less than 180 degree. A short pitched coil is also known as Chorded Coil.
What is short Chorded winding?
Short pitched winding or short chorded winding: If the pitch of the coil is less than 180. 0. or less than the. full pitch then the coil is called short pitched coil. Coil span: Coil span is the distance between two coil sides measured in terms of slots.
What is demerit of short pitch coil?
The disadvantage of using short-pitch winding is that the total voltage around the coils is somewhat reduced. In order to compensate for this reduction in Generated EMF, more number of turns, and therefore more copper is required.
What is the full pitch winding?
Definition of full-pitch winding : the winding of an armature in which the two sides of the armature coil span a distance equal to the pole pitch.
What is full pitched winding?
What is the difference between full pitch and Chorded windings?
A stator winding using fractional pitch coil is called a chorded winding. In case of a full pitch coil, the distance between the two sides of the coil is exactly equal to the pole pitch of 180⁰ electrical. As a result, the voltage in a full pitch coil is such that the voltage of each side of the coil is in phase.
Why armature winding are short pitched?
In actual practice, short pitch coils are used as it has following advantages, 1) The length required for the end connections of coils is less i.e. the inactive length of winding is less. So less copper is required. Hence economical.
Why short pitched armature winding is deliberately used?
Short pitched coils are deliberately used because of: Due to elimination of high frequency harmonics, eddy currents and hysteresis losses; which in turn increases the efficiency. They save copper if end connections, which is a big economic win. They improve the wave form of the generated EMF.
