The KX-TGP500 series brings together all the advantages of modern internet HD VoIP voice calls, classic business phone functionality and easy Web based administration, ideally suited to small office and branch office solutions.

How do I reset my TGP500?

How to Factory Reset a Panasonic TGP500

  1. Ensure the phone and TGP500 base are powered on.
  2. Hold buttons 1-5-9 and * at the same time to initiate the factory reset on the phone (wait for the beep and for the phone to be powered off, and do not power back on).

How do I setup my Panasonic IP phone?

Registering Panasonic IP Phone to S-Series IPPBX

  1. Start up the Panasonic IP phone and identify its IP Address: Press [Menu] Find [System Settings]->[Network Settings]->[IPv4 Settings]->[Static]
  2. Open the web service for the Panasonic VoIP phone. Press [Menu]
  3. Log in the Panasonic IP phone web interface.

How do I restore my Panasonic phone to factory settings?

How to Factory Reset Panasonic Phones

  1. Press the Menu soft key (middle soft key) at the bottom of the screen.
  2. Select System Settings from the menu.
  3. Enter #136 on the keypad.
  4. Select Yes when asked if you are sure you want to factory reset the phone. The phone will be reset successfully after startup.

How do I setup my Panasonic PBX?

First, prepare your Panasonic PBX.

  1. Start the Panasonic Unified Maintenance Console.
  2. Click Connect, verify that you will be doing so at the INSTALLER level and choose the method of connection:
  3. Provide the IP address of the MPR card and the password of the INSTALLER Level.
  4. Click Connect.

What is the Panasonic kx-tgp500?

Sold by Central Valley Goods and ships from Amazon Fulfillment. The Panasonic KX-TGP500 is a Dect solution which includes the base unit and a DECT cordless handset. The KX-TGP500 can be expanded to include up to 6 DECT KX-TPA50 handsets. The Panasonic KX-TGP500 responses to the needs of SIP IP-Centrix/Hosted PBX systems and Asterisk users.

How do I connect my Panasonic kx-tgp5xx to my base?

Connect you Panasonic KX-TGP5XXto the power and network using the LAN port on the Base. You will then need to locate the “ALL” button on the Base. Once Located you will want to register your Handsets to the base following the below instructions: 1. Press the “ALL” button on Base and hold for 4 Seconds 2.

Where can I find the user guide for my Panasonic SIPphone?

•Quick Guide: Explains basic information about the installation and operation of the unit. This guide is provided with the unit or on the Panasonic Web site at: •User Guide: Explains necessary information for end users to operate and customize the unit.
