PE4710, for example, means that the product is made of polyethylene with a “4” rated density, “7” rated slow crack growth class, and has a 1,000-psi maximum recommended HDS with a 0.63 design factor at 23 degrees Celsius in accordance with ASTM D3350 and the stress rating policies in the Plastics Pipe Institute’s PPI- …
What is PE3608?
Pipe made of high density polyethylene — such as PE3408 and PE3608 — is used mainly in industrial and municipal applications such as water mains or sewer and storm drains. This kind of pipe must bear up under both high pressure from within and the weight of the earth from above when buried deeply in a trench.
What is PE4710?
What is High-Performance PE4710 Polyethylene? High-performance polyethylene is an improved polyethylene compound for pressure pipe that is designated PE4710. Compared to conventional pressure piping materials such as PE3408, several important performance characteristics are significantly enhanced.
What is AWWA C901?
ANSI/AWWA C901 UPDATE HEIGHTENS STANDARDS FOR HDPE WATER SERVICE PIPES. It also raises the cell classification for oxidative resistance to CC3 (for potable water piping systems), the highest and only acceptable level of chlorine and chloramine resistance in potable water systems.
Is SDR pipe HDPE?
SDR indicates the amount of pressure (in PSI) a HDPE pipe can withstand. Determining an HDPE pipe’s SDR is fairly simple. The formula is SDR = D/s, where ‘D’ is the outside diameter of the pipe (in millimeters or inches), and ‘s’ is the thickness of the pipe wall (in millimeters or inches).
Is code for DWC pipe?
DWC HDPE PIPE 50/38 MM, Length of Pipe: 6 m, Is Code: 14930
| Length of Pipe | 6 m |
|---|---|
| IS Code | 14930 |
| Usage/Application | DUCTING |
| Color | Any |
| Brand | KESHAV KRIPA |
Is 2508 a standard?
1.1 This standard prescribes the requirements and methods of sampling and test for natural and black colour ( carbon black pigment ) low density polyethylene films intended for packaging, canal lining, agri- cultural operations and post harvest uses, construction work and allied purposes.
What is the difference between IPS and dips HDPE pipe?
IPS sized HDPE pipe has the same outside diameter as black iron or carbon steel pipe. DIPS sized HDPE has the same outside diameter as cast/ductile iron pipe. Typically, ductile iron pipe sizes are available from 4- inch to 36-inch diameters.
What is PEP pipe?
Polyethylene (PE) is a thermoplastic material produced from the polymerization of ethylene. PE plastic pipe is manufactured by extrusion in sizes ranging from ½” to 63″. PE is available in rolled coils of various lengths or in straight lengths up to 40 feet. Iron Pipe Size Inside Diameter, IPS-ID (SIDR)
What kind of pipe is 4710 solid blue?
Charter PE 4710 SOLID BLUE SIDR pipe is color coded to designate water. It has a special stabilizer package to protect the pipe from ultraviolet degradation for up to three years of outdoor storage. Charter Blue is listed with NSF International for use in AWWA Water Service applications.
What is PE4710 material?
The PE4710 material conforms to ASTM D3350 with the cell classification of 445574C/E and is listed with the Plastic Pipe Institute’s (PPI) TR4. It is formulated with carbon black and/or ultraviolet stabilizer for maximum protection against UV rays for added assurance.
What is the scope of HDPE 4710 pressure pipe?
HDPE (4710) HDPE 4710 IPS & DIPS PRESSURE PIPE (8, 10”) Scope: This submittal designates the general requirements for High Density Poly-Ethylene Pressure Pipe from compound with a cell classification PE345464C as defined in ASTM Standard D-3350.
Can charter PE 4710 be used for potable water?
It provides outstanding physical performance and is listed with NSF International for use in potable water applications. This pipe is joined with insert fittings and clamps and is used in water wells, water service and irrigation applications. Charter PE 4710 SOLID BLUE SIDR pipe is color coded to designate water.
