I tried all the export type of 3ds max : but nothing can be done. when open the files : solidworks open emty files….Details.

Created:15 March, 2013
Tags:solidworks 3ds import into

How do I convert solidworks to 3ds?

Create a compatible Mesh file:

  1. Save SOLIDWORKS .STL file from a SOLIDWORKS part file through File > Save as > .STL.
  2. Now open SOLIDWORKS .
  3. The file will then be in a mesh format and can then be exported directly to .3ds file format through File > Save as > Scanto3D Mesh Files.

How do you save a 3ds file in Solidworks?

To export a SOLIDWORKS document that has mesh or cloud point data: Click File > Save As. Select a file format in Save as type: ScanTo3D (*….Select a file format in Save as type:

  1. xyz)
  2. wrl). Click Options to set export options.
  3. stl). Click Options to set export options.
  4. 3ds)
  5. obj)

What is a 3ds file used for?

A 3DS file contains a game ROM of a video game for the Nintendo 3DS (N3DS) handheld console system. It stores a copy of the data from an original game cartridge and can be played on a computer with supporting emulator software.

How do I convert my 3ds to steps?

Convert 3ds To Stp

  1. Download and install the latest version of Filestar.
  2. Right click on one or more 3ds file(s) on your desktop and select Convert with Filestar.
  3. Type convert to stp in the search box.
  4. Press Convert.

Can SolidWorks save as OBJ?

When using Solidworks, the exported models should be in OBJ or DAE format. When using other Solidworks formats, a conversion must be done prior to an upload on Augment, to match Augment requirements.

How do I import a SolidWorks file into 3DS Max?

How to get it and use it?

  1. Download the plugin and install it.
  2. Run 3ds Max.
  3. Go to SimLab Tab and find SolidWorks Importer Tap as shown in the image below:
  4. Click on Settings to open the settings panel that contains import settings and licensing information.

What software uses 3DS files?

Autodesk 3D Studio
Autodesk Inc. 3DS is one of the file formats used by the Autodesk 3ds Max 3D modeling, animation and rendering software. It was the native file format of the old Autodesk 3D Studio DOS (releases 1 to 4), which was popular until its successor (3D Studio MAX 1.0) replaced it in April 1996.

What software opens 3DS?

When all else fails, a universal file viewer is the best way to open a 3DS file. Programs like File Magic (Download) can open many different types of files, depending on the format. Although, some files may not be compatible with these programs. If your 3DS file isn’t compatible, it will only open in binary format.

What files can SolidWorks import?

The user must decide which option will be best depending on how the data will be used. STEP files can be imported as either part files or assembly files. If the file will contain multiple bodies, SOLIDWORKS will import it as a multi-body part by default.

What is 3D SolidWorks?

SolidWorks is a 3D mechanical CAD (computer-aided design) program that runs on Microsoft Windows and is being developed by Dassault Systèmes SolidWorks Corp., a subsidiary of Dassault Systèmes, S. A. (Vélizy, France).

What is the extension for SolidWorks?

Files that contain the .slddrw file extension are most commonly associated with the SolidWorks software application. The SolidWorks CAD program is distributed by the Dassault Systemes SolidWorks Corp . and provides users with 3D software tools that allow users to create, simulate and publish 3D data on their computers.
